Built to Be Trusted
A slim, thermally insulated door system combining elegant linear design with exceptional versatility for pivot, aller-retour and hinged doors in internal and medium-sized openings.
MU2600 Slim Doors
HINGED DOORS
Slim Design
Available with robust, narrow profiles for slim designs.
Design Freedom
Compatible with glass, aluminium panels, HPL and other materials for a wide range of finishes and designs.
Three Door Typologies
Pivot, aller-retour and hinged configurations offer flexibility for different architectural applications.
Smart Access & Security
Compatible with fingerprint recognition, keypads, card access and advanced anti-burglary locking hardware.
System in Detail
- Concealed pivot or aller retour mechanisms can be placed in the middle of the door or off-center, and can adjust the door left – right and up – down.
- Ideal for internal doors or mid-sized frame configurations, with mechanisms that can withstand weight of up to 260 kg.
- Powerful floor rotation mechanism for easy and smooth opening.
- Diverse materials can be used to cover the frame (composite aluminium panels, glass, HPL, panels etc.) providing beautiful and varied combinations of designs options.
- The sash and frame create a unified level surface.
- Several handles are available with a large selection of security locks including electric locks.
- Compatible with specialized locking mechanisms such as fingerprint recognition, keypad, card as well as anti-burglar hardware.
Technical Data MU2600 Slim Doors
Detailed specifications for accurate planning and comparison.
Rail Width: 60 mm
Sash Width: 60 mm
Maximum Sash Weight: 260 kg
Glass Options: Up to 32 mm
Thermal Transmittance – Uw [W/(m²K)]: ≥ 1.4
Sound Reduction: Up to 37 dB
